• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (5V)	11.2
Belt Type	Classic or 358
Number of Grooves	4
Pulley Material	Cast Iron
Number of Hubs	1
Number of Flanges	5
Model Name	45V_LG_Sheavemaster
Bushing Used	E
Outside Diameter (in)	11.3 in
Material	Cast Iron
Bore (Min) (in)	0.875 in
Product Type	Multiple Sheaves
Belt Section	5V
Bore Type	QD Bushed
Face Width (in)	3.0625
Bushing Bore Range	0.875 - 3.500
Length Through Bore (in)	2.64 in

General Specifications

UPC	662289469284
Weight	32.78 LB
Packaged Length	12.50 IN
Packaged Width	12.40 IN
Packaged Height	3.40 IN
