• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Product Type	Gearbelt Pulley
Width (mm)	9.525 mm
Number of teeth	42
Bore Range	5/16 to 1
Model Name	GBPulley_Master1
Material	Aluminium
Bore Type	Rough Bore
Outside Diameter (mm)	67.4116 mm
Width (in)	0.375 in
Outside Diameter (in)	2.654 in
Pitch Diameter (in)	2.674 in
Belt Section	XL
Face Width	0.5625
Hub Diameter (in)	1.5 in
Number of Hubs	1
Length Through Bore	1
Pulley Construction	Solid
Overall Length (in)	1 in
With Flanges	No Flanges
Bore Diameter (in)	0.3125 in
Hub Projection	0.4375

General Specifications

UPC	662289314218
Weight	0.41 LB
Packaged Length	3.20 IN
Packaged Width	3.30 IN
Packaged Height	1.50 IN
HTC	8483.50.9080
Country of Origin	United States of America
