• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Bore Range	1 to 4
Width (mm)	76.2 mm
Number of teeth	40
Product Type	Gearbelt Pulley
Material	Steel
Bore Type	Bushed Bore
Inside Diameter (in)	9.25 in
Outside Diameter (in)	11.031 in
Outside Diameter (mm)	280.1874 mm
Flange (in)	11.6875 in
Belt Section	XH
Width (in)	3 in
Pitch Diameter (in)	11.141 in
Face Width	3.625
Pulley Construction	Solid
Hub Diameter (in)	6.625 in
Overall Length (in)	4.61825 in
With Flanges	With Flanges
Hub Projection	0.99225
Number of Hubs	1
Length Through Bore	3.68

General Specifications

UPC	662289351718
Weight	44.62 LB
Packaged Length	7.60 IN
Packaged Width	14.00 IN
Packaged Height	5.40 IN
HTC	8483.50.9080
Country of Origin	United States of America
