• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Model Name	GBPulley_Master5
Product Type	Gearbelt Pulley
Number of teeth	40
Width (mm)	76.2 mm
Bore Range	3/4 to 2 11/16
Material	Ductile Iron
Bore Type	Bushed Bore
Pitch Diameter (in)	6.366 in
Inside Diameter (in)	4.8125 in
Outside Diameter (mm)	160.3248 mm
Outside Diameter (in)	6.312 in
Width (in)	3 in
Belt Section	H
Flange (in)	6.6000 in
Face Width	3.3125
With Flanges	With Flanges
Overall Length (in)	3.59375 in
Pulley Construction	Solid
Length Through Bore	2.5

General Specifications

UPC	662289144259
Weight	16.39 LB
Packaged Length	9.20 IN
Packaged Width	9.20 IN
Packaged Height	4.40 IN
HTC	8483.50.9080
Country of Origin	United States of America
