• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (C)	9.4
Pulley Material	Cast Iron
Outside Diameter (in)	9.8 in
Model Name	3TC-L_Sheave_Master
Number of Grooves	3
Bushing Used	Q1
Pitch Diameter (C)	9.8
Material	Cast Iron
Overall Length (in)	3.578125 in
Product Type	Multiple Sheaves
Bore (Min) (in)	0.75 in
Belt Section	C
Bore Type	Split Taper Bushed
Bushing Bore Range	2.6875 - 2.6875
Face Width (in)	3.25
Pulley Construction	Spoked
Overall Width (in)	3.53125
Keyway Size	.500

General Specifications

UPC	662289213351
Weight	23.40 LB
Packaged Length	10.06 IN
Packaged Width	10.06 IN
Packaged Height	3.25 IN
HTC	8483.50.9040
Country of Origin	Mexico
