• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	9.4 in
Pitch Diameter (C)	9.4
Number of Grooves	3
Overall Length (in)	3.578125 in
Bushing Used	Q1
Pulley Material	Cast Iron
Model Name	3TC-L_Sheave_Master
Datum Diameter (C)	9
Material	Cast Iron
Belt Section	C
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Pulley Construction	Webbed
Bushing Bore Range	2.6875 - 2.6875
Overall Width (in)	3.53125
Keyway Size	.500
Face Width (in)	3.25

General Specifications

UPC	662289310616
Weight	23.02 LB
Packaged Length	10.70 IN
Packaged Width	10.60 IN
Packaged Height	3.50 IN
