• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Overall Length (in)	3.359375 in
Outside Diameter (in)	9.75 in
Number of Grooves	3
Material	Cast Iron
Bushing Used	R1
Pitch Diameter (5V)	9.65
Pulley Material	Cast Iron
Belt Section	5V
Product Type	Multiple Sheaves
Bore (Min) (in)	1.125 in
Bore Type	Split Taper Bushed
Number of Hubs	1
Keyway Size	0.75
Face Width (in)	2.375
Bushing Bore Range	1.125 - 3.750
Pulley Construction	Web
Overall Width (in)	3.34375

General Specifications

UPC	662289180738
Weight	25.37 LB
Packaged Length	10.30 IN
Packaged Width	10.30 IN
Packaged Height	2.60 IN
