• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Bushing Used	R1
Pitch Diameter (5V)	13.1
Number of Grooves	3
Material	Cast Iron
Outside Diameter (in)	13.2 in
Overall Length (in)	3.359375 in
Product Type	Multiple Sheaves
Belt Section	5V
Bore (Min) (in)	1.125 in
Bore Type	Split Taper Bushed
Keyway Size	.750
Face Width (in)	2.375
Pulley Construction	Spoked
Overall Width (in)	3.34375
Bushing Bore Range	1.125 - 3.750

General Specifications

UPC	662289131068
Weight	31.58 LB
Packaged Length	14.60 IN
Packaged Width	14.30 IN
Packaged Height	2.60 IN
