• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Overall Length (in)	3.359375 in
Number of Grooves	3
Material	Cast Iron
Pitch Diameter (5V)	12.4
Outside Diameter (in)	12.5 in
Bushing Used	R1
Pulley Material	Cast Iron
Product Type	Multiple Sheaves
Bore (Min) (in)	1.125 in
Belt Section	5V
Bore Type	Split Taper Bushed
Keyway Size	.750
Overall Width (in)	3.34375
Bushing Bore Range	1.125 - 3.750
Face Width (in)	2.375
Pulley Construction	Spoked

General Specifications

UPC	662289291045
Weight	33.78 LB
Packaged Length	13.10 IN
Packaged Width	13.20 IN
Packaged Height	2.70 IN
