• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	3
Material	Cast Iron
Pulley Material	Cast Iron
Overall Length (in)	3.171875 in
Bushing Used	R1
Outside Diameter (in)	19 in
Pitch Diameter (3V)	18.95
Bore (Min) (in)	1.125 in
Belt Section	3V
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Pulley Construction	Spoked
Bushing Bore Range	1.125 - 3.750
Face Width (in)	1.5
Keyway Size	.750
Overall Width (in)	3.15625

General Specifications

UPC	662289130221
Weight	32.37 LB
Packaged Length	19.25 IN
Packaged Width	19.20 IN
Packaged Height	2.05 IN
