• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Pitch Diameter (5V)	4.8
Pulley Material	Cast Iron
Bushing Used	Q1
Overall Length (in)	3.453125 in
Number of Grooves	3
Outside Diameter (in)	4.9 in
Bore (Min) (in)	0.75 in
Belt Section	5V
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Bushing Bore Range	2.6875 - 2.6875
Pulley Construction	Plain
Keyway Size	.500
Overall Width (in)	3.40625
Face Width (in)	2.375

General Specifications

UPC	662289486236
Weight	5.32 LB
Packaged Length	5.06 IN
Packaged Width	5.06 IN
Packaged Height	2.50 IN
