• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (3V)	7.95
Material	Cast Iron
Outside Diameter (in)	8 in
Number of Grooves	3
Bushing Used	Q1
Pulley Material	Cast Iron
Overall Length (in)	2.828125 in
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Belt Section	3V
Bore Type	Split Taper Bushed
Pulley Construction	Webbed
Overall Width (in)	2.78125
Keyway Size	.500
Face Width (in)	1.5
Bushing Bore Range	2.6875 - 2.6875

General Specifications

UPC	662289130009
Weight	12.60 LB
Packaged Length	9.06 IN
Packaged Width	9.06 IN
Packaged Height	1.75 IN
