• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Overall Length (in)	2.828125 in
Material	Cast Iron
Pitch Diameter (3V)	10.55
Bushing Used	Q1
Outside Diameter (in)	10.6 in
Number of Grooves	3
Pulley Material	Cast Iron
Product Type	Multiple Sheaves
Belt Section	3V
Bore (Min) (in)	0.75 in
Bore Type	Split Taper Bushed
Overall Width (in)	2.78125
Face Width (in)	1.5
Bushing Bore Range	2.6875 - 2.6875
Pulley Construction	Spoked
Keyway Size	.500

General Specifications

UPC	662289170111
Weight	14.70 LB
Packaged Length	11.60 IN
Packaged Width	11.70 IN
Packaged Height	2.00 IN
