• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	P1
Number of Grooves	3
Pulley Material	Cast Iron
Material	Cast Iron
Outside Diameter (in)	4.5 in
Pitch Diameter (3V)	4.45
Overall Length (in)	2.140625 in
Product Type	Multiple Sheaves
Belt Section	3V
Bore (Min) (in)	0.5 in
Bore Type	Split Taper Bushed
Pulley Construction	Plain
Face Width (in)	1.5
Keyway Size	.375
Bushing Bore Range	0.500 - 1.750
Overall Width (in)	2.1875

General Specifications

UPC	662289249480
Weight	3.99 LB
Packaged Length	4.60 IN
Packaged Width	4.80 IN
Packaged Height	1.60 IN
