• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Pulley Material	Cast Iron
Number of Grooves	3
Bushing Used	P1
Overall Length (in)	2.328125 in
Outside Diameter (in)	4.12 in
Pitch Diameter (3V)	4.07
Product Type	Multiple Sheaves
Belt Section	3V
Bore (Min) (in)	0.5 in
Bore Type	Split Taper Bushed
Bushing Bore Range	0.500 - 1.750
Overall Width (in)	2.375
Face Width (in)	1.5
Pulley Construction	Plain
Keyway Size	.375

General Specifications

UPC	662289269440
Weight	3.25 LB
Packaged Length	4.56 IN
Packaged Width	4.56 IN
Packaged Height	1.56 IN
