• Large Selection - MVP companion sheaves are offered in A/B, C, 5Vand 8V belt sections and from 3-10 grooves giving Browning the largest selection of MVP Companion Sheaves in the industry.
• Statically Balanced - All MVP companion sheaves are statically balanced to assure smooth, vibration free performance.
• VP sheaves consist of a male with a threaded barrel, and a female with a threaded bore.
• The male section with threaded barrel has flat surfaces at 180 degree increments that allow a flat surface for the setscrew to mate with.
• When discs are moved toward each other, the belt rides higher in the groove and the pitch diameter of the sheave is larger which increases the driven speed.
• When discs are moved away from each other, the belt rides lower and the pitch diameter is smaller decreasing the driven speed.

Technical Specifications

Material	Cast Iron
Type of Bore	Finished
Pitch Diameter Range (A)	6.7 - 5.6
Pitch Diameter Range (B)	7.2 - 5.8
Face Width (Max) (in)	3.4375 in
Outside Length (in)	4.75 in
Outside Diameter (in)	7.18 in
Ring	4.375
Face Width (Min) (in)	3.0625 in
Product Type	MVP Sheaves
Number of Grooves	3
Belt Section	A, B
Bore (in)	1.375 in
Bore Type	Finished with Keyway and SS
Keyway Size	.3125
Set Screw Thread	3/8-16 UNC-3AX5/8
Set Screw Tightening Torque (in-lb)	290

General Specifications

UPC	662289312771
Weight	24.50 LB
Packaged Length	7.18 IN
Packaged Width	7.18 IN
Packaged Height	4.75 IN
HTC	8483.50.9040
Country of Origin	United States of America
