• Large Selection - MVP companion sheaves are offered in A/B, C, 5Vand 8V belt sections and from 3-10 grooves giving Browning the largest selection of MVP Companion Sheaves in the industry.
• Statically Balanced - All MVP companion sheaves are statically balanced to assure smooth, vibration free performance.
• VP sheaves consist of a male with a threaded barrel, and a female with a threaded bore.
• The male section with threaded barrel has flat surfaces at 180 degree increments that allow a flat surface for the setscrew to mate with.
• When discs are moved toward each other, the belt rides higher in the groove and the pitch diameter of the sheave is larger which increases the driven speed.
• When discs are moved away from each other, the belt rides lower and the pitch diameter is smaller decreasing the driven speed.

Technical Specifications

Outside Length (in)	3.578125 in
Number of Grooves	3
Pitch Diameter Range (A)	7.2
Material	Cast Iron
Outside Diameter (in)	7.75 in
Type of Bore	Bushed
Product Type	MVP Sheaves
Pitch Diameter Range (B)	7.7
Bore (Min) (in)	0.75 in
Belt Section	A, B
Pulley Construction	Webbed
Face Width (in)	3.25 in
Bore Type	Split Taper Bushed
Bore (Max) (in)	2.6875 in
Bushing Used	Q1
Keyway Size	.500
Bushing Bore Range	2.6875 - 2.6875

General Specifications

UPC	662289145621
Weight	21.39 LB
Packaged Length	8.50 IN
Packaged Width	8.50 IN
Packaged Height	3.40 IN
HTC	8483.50.9040
Country of Origin	Mexico
