• Wrapped construction - Browning offers a full line of wrapped FHP Belts which provides smooth quiet operation. Wrapped FHP Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• The best features of notched and wrapped belts. Designed for small sheave applications - Browning FHP Belts are formulated for maximum flexibility for use in small diameter sheaves.

Technical Specifications

Pitch Length	30.3
Belt Section	3L
Standards met	ARPM IP-23
Reinforcing cord material	Polyester
Color	Black
Material	Rubber
Belt Series	FHP Belts
Construction Type	Wrapped
Section Size	3L
Overall Width (in)	0.375 in
Product Type	FHP Belt
Outside Length/Diameter (in)	31 in
Cross Section	0.375
Operating Temperature [Max] ºC	60 °C
Operating Temperature [Max] ºF	140 °F
Width (in)	0.375 in
Operating Temperature Range	-32 to +140 °F
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3
Part Height	0.219

General Specifications

UPC	662289145119
Weight	0.13 LB
Packaged Length	4.15 IN
Packaged Width	13.50 IN
Packaged Height	0.95 IN
HTC	4010.32.3000
Country of Origin	Mexico
