• Wrapped construction - Browning offers a full line of wrapped FHP Belts which provides smooth quiet operation. Wrapped FHP Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• The best features of notched and wrapped belts. Designed for small sheave applications - Browning FHP Belts are formulated for maximum flexibility for use in small diameter sheaves.

Technical Specifications

Pitch Length	29.3
Belt Section	3L
Color	Black
Material	Rubber
Construction Type	Wrapped
Belt Series	FHP Belts
Reinforcing cord material	Polyester
Section Size	3L
Standards met	ARPM IP-23
Product Type	FHP Belt
Outside Length/Diameter (in)	30 in
Overall Width (in)	0.375 in
Operating Temperature [Max] ºF	140 °F
Cross Section	0.375
Operating Temperature [Max] ºC	60 °C
Width (in)	0.375 in
Operating Temperature Range	-32 to +140 °F
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3
Part Height	0.219

General Specifications

UPC	662289295098
Weight	0.12 LB
Packaged Length	3.40 IN
Packaged Width	13.05 IN
Packaged Height	0.55 IN
HTC	4010.32.3000
Country of Origin	Mexico
