• Wrapped construction - Browning offers a full line of wrapped FHP Belts which provides smooth quiet operation. Wrapped FHP Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• The best features of notched and wrapped belts. Designed for small sheave applications - Browning FHP Belts are formulated for maximum flexibility for use in small diameter sheaves.

Technical Specifications

Belt Section	3L
Pitch Length	25.3
Construction Type	Wrapped
Color	Black
Belt Series	FHP Belts
Standards met	ARPM IP-23
Reinforcing cord material	Polyester
Section Size	3L
Material	Rubber
Operating Temperature [Max] ºC	60 °C
Product Type	FHP Belt
Overall Width (in)	0.375 in
Operating Temperature [Max] ºF	140 °F
Outside Length/Diameter (in)	26 in
Cross Section	0.375
Width (in)	0.375 in
Operating Temperature Range	-32 to +140 °F
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3
Part Height	0.219

General Specifications

UPC	662289255054
Weight	0.11 LB
Packaged Length	3.05 IN
Packaged Width	11.30 IN
Packaged Height	0.55 IN
HTC	4010.32.3000
Country of Origin	Romania
