• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Hubs	1
Number of Flanges	4
Number of Grooves	3
Pulley Material	Cast Iron
Pitch Diameter (C)	20.4
Overall Length (in)	3.796875 in
Material	Cast Iron
Belt Type	Classic or 358
Bushing Used	R1
Datum Diameter (C)	20
Outside Diameter (in)	20.4 in
Product Type	Multiple Sheaves
Belt Section	C
Bore (Min) (in)	1.125 in
Bore Type	Split Taper Bushed
Bushing Bore Range	1.125 - 3.750
Face Width (in)	3.25
Keyway Size	.750

General Specifications

UPC	662289227082
Weight	58.00 LB
Packaged Length	20.40 IN
Packaged Width	20.40 IN
Packaged Height	3.25 IN
