• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Overall Length (in)	3.796875 in
Datum Diameter (C)	12
Bushing Used	R1
Number of Grooves	3
Pitch Diameter (C)	12.4
Pulley Material	Cast Iron
Outside Diameter (in)	12.4 in
Bore (Min) (in)	1.125 in
Belt Section	C
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Bushing Bore Range	1.125 - 3.750
Keyway Size	.750

General Specifications

UPC	662289216512
Weight	32.20 LB
Packaged Length	12.75 IN
Packaged Width	12.75 IN
Packaged Height	3.25 IN
