• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Number of Grooves	3
Datum Diameter (C)	10.6
Material	Cast Iron
Bushing Used	R1
Pitch Diameter (C)	11
Overall Length (in)	3.796875 in
Outside Diameter (in)	11 in
Product Type	Multiple Sheaves
Belt Section	C
Bore (Min) (in)	1.125 in
Bore Type	Split Taper Bushed
Number of Hubs	1
Keyway Size	0.75
Pulley Construction	Web
Overall Width (in)	3.78125
Bushing Bore Range	1.125 - 3.750
Face Width (in)	3.25

General Specifications

UPC	662289311217
Weight	32.24 LB
Packaged Length	11.70 IN
Packaged Width	11.80 IN
Packaged Height	3.50 IN
HTC	8483.50.9040
Country of Origin	Mexico
