• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (A)	6.6
Number of Grooves	3
Outside Diameter (in)	7.15 in
Pitch Diameter (B)	7.1
Datum Diameter (A)	6.4
Material	Cast Iron
Pulley Material	Cast Iron
Datum Diameter (B)	6.8
Model Name	3AB_LG_Sheavemaster
Bushing Used	SD
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Belt Section	A, B
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 2.000

General Specifications

UPC	662289383122
Weight	11.35 LB
Packaged Length	7.19 IN
Packaged Width	7.19 IN
Packaged Height	2.50 IN
