• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (A)	5.8
Bushing Used	SD
Model Name	3AB_LG_Sheavemaster
Pulley Material	Cast Iron
Pitch Diameter (A)	6
Material	Cast Iron
Outside Diameter (in)	6.55 in
Datum Diameter (B)	6.2
Pitch Diameter (B)	6.5
Number of Grooves	3
Belt Section	A, B
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 2.000
Pulley Construction	Plain
Face Width (in)	2.5
Overall Width (in)	2.5
Length Through Bore (in)	1.8125 in

General Specifications

UPC	662289373147
Weight	11.04 LB
Packaged Length	7.10 IN
Packaged Width	7.30 IN
Packaged Height	2.80 IN
