• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Datum Diameter (A)	9
Overall Length (in)	2.90625 in
Datum Diameter (B)	9.4
Pulley Material	Cast Iron
Pitch Diameter (B)	9.7
Material	Cast Iron
Model Name	3B5V-SheaveMaster
Bushing Used	B
Outside Diameter (in)	9.68 in
Pitch Diameter (A)	9.2
Number of Grooves	3
Pitch Diameter (5V)	9.5
Belt Section	A, B, 5V
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Number of Hubs	1
Pulley Construction	Spoke
Face Width (in)	2.44
Bushing Bore Range	.500 - 2.4375
Keyway Size	0.5
Overall Width (in)	2.92

General Specifications

UPC	662289037810
Weight	15.99 LB
Packaged Length	10.40 IN
Packaged Width	10.30 IN
Packaged Height	2.80 IN
