• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Pitch Diameter (B)	6.9
Pitch Diameter (A)	6.4
Overall Length (in)	2.90625 in
Model Name	3B5V-SheaveMaster
Datum Diameter (B)	6.6
Pitch Diameter (5V)	6.7
Outside Diameter (in)	6.88 in
Datum Diameter (A)	6.2
Number of Grooves	3
Pulley Material	Cast Iron
Bushing Used	B
Material	Cast Iron
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Belt Section	A, B, 5V
Number of Hubs	1
Bore Type	Split Taper Bushed
Pulley Construction	Solid
Bushing Bore Range	.500 - 2.4375
Keyway Size	0.5
Face Width (in)	2.44
Overall Width (in)	2.89

General Specifications

UPC	662289035212
Weight	11.61 LB
Packaged Length	7.80 IN
Packaged Width	7.80 IN
Packaged Height	2.80 IN
