• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Datum Diameter (A)	4.2
Pulley Material	Cast Iron
Overall Length (in)	3.5 in
Pitch Diameter (B)	4.9
Number of Grooves	3
Model Name	3B5V-SheaveMaster
Bushing Used	B
Pitch Diameter (5V)	4.7
Datum Diameter (B)	4.6
Outside Diameter (in)	4.88 in
Material	Cast Iron
Pitch Diameter (A)	4.4
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Belt Section	A, B, 5V
Number of Hubs	1
Bore Type	Split Taper Bushed
Pulley Construction	Solid
Keyway Size	0.5
Overall Width (in)	3.52
Face Width (in)	2.44
Bushing Bore Range	.500 - 2.4375

General Specifications

UPC	662289034963
Weight	4.76 LB
Packaged Length	5.20 IN
Packaged Width	5.50 IN
Packaged Height	2.60 IN
