• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Pitch Diameter (5V)	27.9
Bushing Used	B
Pitch Diameter (B)	28.1
Material	Cast Iron
Datum Diameter (A)	27.3
Pitch Diameter (A)	27.5
Pulley Material	Cast Iron
Datum Diameter (B)	27.8
Overall Length (in)	2.90625 in
Outside Diameter (in)	28.08 in
Model Name	3B5V-SheaveMaster
Number of Grooves	3
Bore (Min) (in)	0.5 in
Belt Section	A, B, 5V
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Face Width (in)	2.4375
Overall Width (in)	2.84375
Bushing Bore Range	0.500 - 2.4375
Pulley Construction	Spoked
Keyway Size	.500

General Specifications

UPC	662289034871
Weight	79.35 LB
Packaged Length	28.08 IN
Packaged Width	28.08 IN
Packaged Height	2.44 IN
