• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Model Name	3AB_LG_Sheavemaster
Datum Diameter (B)	5.8
Outside Diameter (in)	6.15 in
Number of Grooves	3
Pulley Material	Cast Iron
Datum Diameter (A)	5.4
Pitch Diameter (A)	5.6
Bushing Used	SD
Pitch Diameter (B)	6.1
Material	Cast Iron
Bore (Min) (in)	0.5 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Overall Width (in)	2.5
Bushing Bore Range	0.500 - 2.000
Pulley Construction	Plain
Face Width (in)	2.5
Length Through Bore (in)	1.8125 in

General Specifications

UPC	662289413096
Weight	9.54 LB
Packaged Length	6.63 IN
Packaged Width	6.63 IN
Packaged Height	2.63 IN
