• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Model Name	3AB_LG_Sheavemaster
Material	Cast Iron
Number of Grooves	3
Datum Diameter (A)	4.2
Outside Diameter (in)	4.95 in
Pitch Diameter (B)	4.9
Pulley Material	Cast Iron
Bushing Used	SD
Datum Diameter (B)	4.6
Pitch Diameter (A)	4.4
Belt Section	A, B
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Number of Hubs	1
Bore Type	QD Bushed
Overall Width (in)	2.5
Bushing Bore Range	.500 - 2.000
Face Width (in)	2.5
Pulley Construction	Solid

General Specifications

UPC	662289321032
Weight	5.46 LB
Packaged Length	5.20 IN
Packaged Width	5.40 IN
Packaged Height	2.70 IN
