• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (B)	3.6
Number of Flanges	4
Number of Grooves	3
Outside Diameter (in)	3.95 in
Belt Type	Classic or 358
Material	Cast Iron
Model Name	3AB_LG_Sheavemaster
Datum Diameter (A)	3.2
Bushing Used	SH
Pulley Material	Cast Iron
Pitch Diameter (B)	3.9
Number of Hubs	1
Pitch Diameter (A)	3.4
Belt Section	A, B
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 1.625
Face Width (in)	2.5
Length Through Bore (in)	1.2 in

General Specifications

UPC	662289392995
Weight	3.66 LB
Packaged Length	4.19 IN
Packaged Width	4.19 IN
Packaged Height	2.50 IN
