• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (A)	29.8
Pitch Diameter (B)	30.3
Material	Cast Iron
Bushing Used	R1
Number of Grooves	3
Outside Diameter (in)	30.35 in
Pulley Material	Cast Iron
Datum Diameter (A)	29.6
Overall Length (in)	3.421875 in
Datum Diameter (B)	30
Bore (Min) (in)	1.125 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Keyway Size	.750
Overall Width (in)	3.40625
Face Width (in)	2.5
Bushing Bore Range	1.125 - 3.750
Pulley Construction	Spoked

General Specifications

UPC	662289311064
Weight	89.00 LB
Packaged Length	30.35 IN
Packaged Width	30.35 IN
Packaged Height	2.50 IN
