• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Number of Grooves	3
Pulley Material	Cast Iron
Datum Diameter (B)	16
Overall Length (in)	3.421875 in
Outside Diameter (in)	16.35 in
Bushing Used	R1
Datum Diameter (A)	15.6
Pitch Diameter (B)	16.3
Pitch Diameter (A)	15.8
Bore (Min) (in)	1.125 in
Product Type	Multiple Sheaves
Belt Section	A, B
Bore Type	Split Taper Bushed
Bushing Bore Range	1.125 - 3.750
Pulley Construction	Spoked
Overall Width (in)	3.40625
Face Width (in)	2.5
Keyway Size	.750

General Specifications

UPC	662289195275
Weight	39.79 LB
Packaged Length	17.20 IN
Packaged Width	17.10 IN
Packaged Height	3.50 IN
