• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Datum Diameter (B)	15.4
Pitch Diameter (A)	15.2
Datum Diameter (A)	15
Outside Diameter (in)	15.75 in
Overall Length (in)	3.421875 in
Bushing Used	R1
Pitch Diameter (B)	15.7
Number of Grooves	3
Material	Cast Iron
Bore (Min) (in)	1.125 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Overall Width (in)	3.40625
Pulley Construction	Spoked
Bushing Bore Range	1.125 - 3.750
Keyway Size	.750
Face Width (in)	2.5

General Specifications

UPC	662289145126
Weight	36.69 LB
Packaged Length	16.30 IN
Packaged Width	16.30 IN
Packaged Height	2.70 IN
