• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Model Name	GBPulley_Master1
Bore Range	5/16 to 1
Number of teeth	36
Width (mm)	9.525 mm
Product Type	Gearbelt Pulley
Material	Aluminium
Bore Type	Rough Bore
Outside Diameter (mm)	57.7088 mm
Outside Diameter (in)	2.272 in
Pitch Diameter (in)	2.292 in
Width (in)	0.375 in
Belt Section	XL
Face Width	0.5625
Pulley Construction	Solid
Number of Hubs	1
Hub Diameter (in)	1.5 in
Hub Projection	0.4375
Bore Diameter (in)	0.3125 in
Overall Length (in)	1 in
Length Through Bore	1
With Flanges	No Flanges

General Specifications

UPC	662289292127
Weight	0.32 LB
Packaged Length	2.60 IN
Packaged Width	2.60 IN
Packaged Height	1.40 IN
HTC	8483.50.9080
Country of Origin	United States of America
