• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Width (mm)	25.4 mm
Number of teeth	36
Bore Range	3/8 to 1 1/2
Product Type	Gearbelt Pulley
Material	Steel
Bore Type	Bushed Bore
Pitch Diameter (in)	4.297 in
Belt Section	L
Flange (in)	4.5200 in
Width (in)	1 in
Outside Diameter (in)	4.267 in
Outside Diameter (mm)	108.3818 mm
Face Width	1.25
Pulley Construction	Solid
Length Through Bore	1.276
With Flanges	With Flanges
Overall Length (in)	1.57 in

General Specifications

UPC	662289113576
Weight	3.53 LB
Packaged Length	4.80 IN
Packaged Width	4.70 IN
Packaged Height	2.00 IN
HTC	8483.50.9080
Country of Origin	United States of America
