• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	SF
Number of Grooves	3
Material	Cast Iron
Outside Diameter (in)	9 in
Belt Type	Classic or 358
Pitch Diameter (5V)	8.9
Number of Hubs	1
Pulley Material	Cast Iron
Model Name	35V_LG_Sheavemaster
Number of Flanges	4
Belt Section	5V
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Overall Width (in)	2.375
Bushing Bore Range	.500 - 2.9375
Pulley Construction	Spoke
Face Width (in)	2.375

General Specifications

UPC	662289321391
Weight	20.00 LB
Packaged Length	10.40 IN
Packaged Width	10.40 IN
Packaged Height	2.90 IN
