• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Model Name	35V_LG_Sheavemaster
Bushing Used	SF
Material	Cast Iron
Outside Diameter (in)	8.5 in
Pitch Diameter (5V)	8.4
Pulley Material	Cast Iron
Number of Grooves	3
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Belt Section	5V
Number of Hubs	1
Bore Type	QD Bushed
Bushing Bore Range	.500 - 2.9375
Pulley Construction	Spoke
Overall Width (in)	2.375
Face Width (in)	2.375

General Specifications

UPC	662289366279
Weight	18.06 LB
Packaged Length	9.70 IN
Packaged Width	9.60 IN
Packaged Height	3.80 IN
