• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Pitch Diameter (5V)	6.6
Number of Grooves	3
Bushing Used	SK
Outside Diameter (in)	6.7 in
Model Name	35V_LG_Sheavemaster
Pulley Material	Cast Iron
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Belt Section	5V
Bore Type	QD Bushed
Face Width (in)	2.375
Pulley Construction	Plain
Bushing Bore Range	0.500 - 2.625
Overall Width (in)	2.375

General Specifications

UPC	662289469215
Weight	10.90 LB
Packaged Length	7.19 IN
Packaged Width	7.19 IN
Packaged Height	2.50 IN
