• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	3
Bushing Used	SDS
Model Name	35V_LG_Sheavemaster
Outside Diameter (in)	5.9 in
Pitch Diameter (5V)	5.8
Pulley Material	Cast Iron
Material	Cast Iron
Bore (Min) (in)	0.5 in
Belt Section	5V
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 2.000
Pulley Construction	Plain
Face Width (in)	2.375
Overall Width (in)	2.375
Length Through Bore (in)	1.3125 in

General Specifications

UPC	662289469055
Weight	7.99 LB
Packaged Length	6.50 IN
Packaged Width	6.30 IN
Packaged Height	2.60 IN
