• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Flanges	4
Model Name	35V_LG_Sheavemaster
Belt Type	Classic or 358
Pitch Diameter (5V)	18.6
Number of Grooves	3
Pulley Material	Cast Iron
Number of Hubs	1
Outside Diameter (in)	18.7 in
Material	Cast Iron
Bushing Used	E
Belt Section	5V
Product Type	Multiple Sheaves
Bore (Min) (in)	0.875 in
Bore Type	QD Bushed
Face Width (in)	2.375
Length Through Bore (in)	2.64 in

General Specifications

UPC	662289471133
Weight	54.00 LB
Packaged Length	18.70 IN
Packaged Width	18.70 IN
Packaged Height	2.37 IN
