• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (5V)	13.9
Number of Grooves	3
Outside Diameter (in)	14 in
Model Name	35V_LG_Sheavemaster
Material	Cast Iron
Number of Hubs	1
Bushing Used	E
Pulley Material	Cast Iron
Number of Flanges	4
Belt Type	Classic or 358
Product Type	Multiple Sheaves
Belt Section	5V
Bore (Min) (in)	0.875 in
Bore Type	QD Bushed
Bushing Bore Range	0.875 - 3.500
Face Width (in)	2.375
Length Through Bore (in)	2.64 in

General Specifications

UPC	662289413577
Weight	34.16 LB
Packaged Length	14.00 IN
Packaged Width	14.00 IN
Packaged Height	2.50 IN
