• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Number of Grooves	3
Pitch Diameter (5V)	12.4
Model Name	35V_LG_Sheavemaster
Outside Diameter (in)	12.5 in
Bushing Used	E
Pulley Material	Cast Iron
Belt Section	5V
Product Type	Multiple Sheaves
Bore (Min) (in)	0.875 in
Bore Type	QD Bushed
Overall Width (in)	2.375
Pulley Construction	Spoked
Bushing Bore Range	0.875 - 3.500
Face Width (in)	2.375
Length Through Bore (in)	2.75 in

General Specifications

UPC	662289363513
Weight	32.39 LB
Packaged Length	13.20 IN
Packaged Width	13.00 IN
Packaged Height	2.90 IN
