• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Hubs	1
Pitch Diameter (5V)	11.7
Material	Cast Iron
Pulley Material	Cast Iron
Bushing Used	SF
Belt Type	Classic or 358
Number of Grooves	3
Model Name	35V_LG_Sheavemaster
Number of Flanges	4
Outside Diameter (in)	11.8 in
Belt Section	5V
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Face Width (in)	2.375
Bushing Bore Range	0.500 - 2.938

General Specifications

UPC	662289406234
Weight	25.30 LB
Packaged Length	12.75 IN
Packaged Width	12.75 IN
Packaged Height	2.63 IN
