• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Width (mm)	101.6 mm
Product Type	Gearbelt Pulley
Number of teeth	32
Bore Range	1 3/8 to 3 5/8
Material	Steel
Bore Type	Bushed Bore
Width (in)	4 in
Flange (in)	9.4375 in
Outside Diameter (mm)	223.5962 mm
Inside Diameter (in)	7 in
Pitch Diameter (in)	8.913 in
Outside Diameter (in)	8.803 in
Belt Section	XH
Face Width	4.6875
Pulley Construction	Solid
With Flanges	With Flanges
Hub Projection	0.46925
Overall Length (in)	5.15625 in
Hub Diameter (in)	5.375 in
Number of Hubs	1
Length Through Bore	4.875

General Specifications

UPC	662289184606
Weight	50.50 LB
Packaged Length	9.75 IN
Packaged Width	9.75 IN
Packaged Height	4.75 IN
HTC	8483.50.9080
Country of Origin	United States of America
