• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Bore Range	1 1/8 to 3 3/4
Product Type	Gearbelt Pulley
Number of teeth	32
Width (mm)	76.2 mm
Bore Type	Bushed Bore
Material	Steel
Width (in)	3 in
Outside Diameter (mm)	223.5962 mm
Pitch Diameter (in)	8.913 in
Outside Diameter (in)	8.803 in
Flange (in)	9.4375 in
Inside Diameter (in)	7 in
Belt Section	XH
Face Width	3.625
Overall Length (in)	3.625 in
With Flanges	With Flanges
Length Through Bore	2.875
Pulley Construction	Solid

General Specifications

UPC	662289154517
Weight	32.10 LB
Packaged Length	10.20 IN
Packaged Width	10.50 IN
Packaged Height	6.30 IN
HTC	8483.50.9080
Country of Origin	United States of America
