• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Bore Range	7/8 to 3 1/2
Width (mm)	76.2 mm
Product Type	Gearbelt Pulley
Number of teeth	32
Material	Steel
Bore Type	Bushed Bore
Width (in)	3 in
Flange (in)	9.4375 in
Belt Section	XH
Outside Diameter (in)	8.803 in
Inside Diameter (in)	7 in
Outside Diameter (mm)	223.5962 mm
Pitch Diameter (in)	8.913 in
Face Width	3.375
Length Through Bore	2.64
With Flanges	With Flanges
Hub Diameter (in)	6 in
Number of Hubs	1
Pulley Construction	Solid
Hub Projection	0.45
Overall Length (in)	3.82225 in

General Specifications

UPC	662289350377
Weight	32.65 LB
Packaged Length	10.40 IN
Packaged Width	10.60 IN
Packaged Height	6.30 IN
HTC	8483.50.9080
Country of Origin	United States of America
