• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Bore Range	1/2 to 2 5/8
Number of teeth	32
Product Type	Gearbelt Pulley
Model Name	GBPulley_Master6
Width (mm)	25.4 mm
Material	Steel
Bore Type	Bushed Bore
Width (in)	1.5 in
Inside Diameter (in)	4.125 in
Outside Diameter (mm)	127.9906 mm
Flange (in)	5.3125 in
Belt Section	H
Pitch Diameter (in)	5.093 in
Outside Diameter (in)	5.039 in
Face Width	1.8125
Number of Hubs	1
Hub Diameter (in)	3.875 in
Overall Length (in)	2.03125 in
Hub Projection	0.21875
Pulley Construction	Solid
With Flanges	With Flanges
Length Through Bore	1.75

General Specifications

UPC	662289350094
Weight	5.21 LB
Packaged Length	6.40 IN
Packaged Width	6.30 IN
Packaged Height	2.70 IN
HTC	8483.50.9080
Country of Origin	United States of America
