• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Product Type	Gearbelt Pulley
Width (mm)	19.05 mm
Number of teeth	30
Bore Range	58 to 1 3/8
Bore Type	Rough Bore
Material	Steel
Outside Diameter (in)	3.551 in
Flange (in)	3.800 in
Outside Diameter (mm)	90.1954 mm
Width (in)	0.75 in
Pitch Diameter (in)	3.581 in
Belt Section	L
Face Width	1
Number of Hubs	1
Length Through Bore	1.5
Overall Length (in)	1.5 in
Hub Diameter (in)	2.25 in
Hub Projection	0.5
Pulley Construction	Solid
Bore Diameter (in)	0.625 in
With Flanges	With Flanges

General Specifications

UPC	662289292356
Weight	2.95 LB
Packaged Length	4.60 IN
Packaged Width	4.70 IN
Packaged Height	2.00 IN
HTC	8483.50.9080
Country of Origin	United States of America
